Power
12-24VDC
Installation
Inside the hull
Lumens
10,000 or 14,000
Powerful Illumination
The DeepSea Retro LED is available with blue or white LED on 12/24 VDC power and 10,000 lumens, or with white LED on 24 VDC power only and 14,000 lumens. The LEDs have a beam angle of 100 degrees through a flat lens, providing a perfect spread of light.
Power Supply Recommendation
If you are using the original AC power supply, we recommend using the MeanWell ELG-150 or a similarly specified product. The 12/24 VDC output must be fused.
Maintenance
Inside the hull
Control option
On/Off
Driver
Integral
Power
12-24VDC
Installation
Inside the hull
Lens & test
N/A
Hull material
N/A
Boat size
N/A
Lumens
10,000 (12/24 VDC, Blue/White)
14,000 (24 VDC, White)
Kelvin
6500K White and Blue only
Beam angle
100 degrees
Colour: Blue or White
Operating Voltage: 12-24VDC
Current Amp draw: 10,000 lumens @ 7-3.5A / 14,000 lumens @ 4 A
